We have expanded our portfolio of popular precision laser receivers with the new high-performance LZ-75 laser target, which offers two-dimensional determination of position and orientation. The frequent requirement to determine the position of a dot-shaped laser beam on a plane arises from various application profiles and can be solved universally and flexibly with the LZ-75.
Possible applications
The reference of the measurement is always a dot-shaped laser beam. For example, you project a centre point on the ground vertically upwards with our plumb laser. The relative position of components or constructions above it is determined automatically with the attached laser target and sent to a laptop, for example by wireless transmission. The position is thus determined virtually in real time and can be monitored or corrected.
With a horizontal beam laser, this arrangement can of course also be transmitted for alignment work along a reference axis.
Mit dem Laden des Videos akzeptieren Sie die Datenschutzerklärung von YouTube.
Mehr erfahren
Thanks to continuous data transmission, the LZ-75 can also be used easily for monitoring systems. For example, to monitor a tower’s continuous movement in the wind, it suffices to place a precision plumb laser on the foundation and an LZ-75 target in the upper area. The position data is available almost in real time and can be evaluated and stored easily. An alarm in the case of critical changes from the reference position is a useful by-product.
Mit dem Laden des Videos akzeptieren Sie die Datenschutzerklärung von YouTube.
Mehr erfahren
If you project a reference axis into a space with a laser beam, regardless of whether it is vertical or horizontal, it is possible to scan any component or structure geometries with the LZ-75 and thus determine the actual position relative to the reference position. Whether for measuring the torsions of a rail structure, the correct alignment of attachments or the lateral movements of a lift in a lift shaft, these tasks are no longer particular challenges with the LZ-75.
Mit dem Laden des Videos akzeptieren Sie die Datenschutzerklärung von YouTube.
Mehr erfahren
Like all GEO products, the LZ-75 is designed for harsh environmental conditions and tough industrial and construction site use. The completely waterproof metal housing is filled with nitrogen and protects its internal components lastingly and permanently. The modular design enables data transmission via analogue means, Ethernet and various wireless standards. Power can be supplied externally or via an integrated rechargeable Li-ion battery.
The measured values can be evaluated and displayed using the customer’s own software solution or with software from us. The simultaneous display and evaluation of several receivers is of course possible.
Due to our extensive portfolio of different lasers for different accuracy and application requirements, we can offer you a complete coordinate measuring system from one source. And as with all our products, GEO also stands with this product not only for highest quality, but also for flexible and customer-specific solutions.
Talk to us and challenge us!
